Outsourced Semiconductor Assembly & Test

Assembly and test are aligned across three dimensions:

Process Alignment

Package configuration, screening logic, and test coverage are defined together, not sequentially.

Data Continuity

Wafer-level data, final test results, and yield learning are correlated within a common production framework.

Ramp Discipline

Scale expansion follows demonstrated yield behaviour across both assembly and test, preventing misalignment between throughput and validation.

Leadframe & Wirebond Platforms

  • QFN
  • DFN
  • SOT
  • TO / TO-247
  • IPM
  • Wire Bond BGA

Flip-Chip & High-Density Platforms

  • FC-QFN
  • FC-BGA
  • System-in-Package (SiP)
  • Stack Die

Specialised Platforms

  • MEMS packaging
  • Photonics-based configurations
  • ROSA / TOSA

Supports automotive, power, RF, MEMS, and industrial programs requiring controlled integration.

Test operations are integrated directly within the assembly control structure.

Wafer-Level Services

  • Wafer sort
  • Wafer-Level Burn-In (WLBI)
  • Known Good Die enablement

Final & Strip Test

  • Room temperature
  • Dual temperature
  • Tri-temperature (-55°C to 155°C)

Power & Automotive Devices

  • SiC
  • GaN
  • IGBT
  • Power modules

Manufacturing Infrastructure

  • Integrated assembly and final test operations
  • Multi-line production configuration
  • Phased capacity expansion
  • Production governance aligned to semiconductor-grade standards

Market Context

Supporting semiconductor programs in automotive, power electronics, RF, MEMS, photonics, and industrial systems where controlled production behaviour is critical.

India’s semiconductor future will be built on execution, not intent. We are here to build that execution.
